The Defacto Standard in exterior coatings
Polyester TGIC
Polyester TGIC powders are exterior durable coatings that offer good mechanical and chemical resistance properties in the range of 1 to 5.0 + mils. These coatings will also cure at lower temperatures than the standard polyester urethane. Polyester TGIC products are available in General Industrial or Super Durable platforms
Typical Applications For Polyester - TGIC Powders:
Lawn and Patio Furniture, Irrigation Equipment, Playground Equipment, Lawn and Garden Equipment, Fencing, Satellite Dishes, Generators, Heavy Equipment, Farm Implements, Aluminum Extrusions, Recreation Vehicles
| Category | Properties | Notes |
|---|---|---|
| Color | All Colors and Clear | |
| Specific Gravity | 1.2 - 1.8 | depending on color and formulation |
| 60° Gloss | 5% - 95% | Per ASTM D523 |
| Hardness | HB to H | Per ASTM D3363 |
| Impact | 60 to 160 inch pounds | Per ASTM D2794 |
| Adhesion - Crosshatch | 100% Pass | Per ASTM D3359 |
| Solvent Resistance | 50 Double Rubs | Per PT-310-070 90/10, softens but recovers |
| Salt Spray | 1,000+ Hours | Per ASTM D1654, when applied to properly cleaned and pretreated substrates |
| Humidity | 1,000+ Hours | Per ASTM D2247, when applied to properly cleaned and pretreated substrates |
| Cure Range | From 20' @ 325° to 10' @ 400° | Metal Temperature |
ULTRA-HIGH QUV RATED AAMA COMPLIANT COATINGS
Pentabond©, (P500) Series AAMA 2604 Polyester
Pentabond technology is based on proprietary polyester technology and is formulated specifically to meet the requirements of AAMA 2604. In addition to resin technology, the selection of additives, pigments and fillers was done to maximize physical properties after extended outdoor exposure while maintaining high levels of gloss and color retention.
Minimum 30% gloss retention after 5 years Florida exposure
Maximum of 5 Delta E units, (Hunter), of color change as calculated in accordance with ASTM D 2244, Section 6.3
Limited Warranty is available for select color/gloss combinations
Decabond©, (D1000) Series AAMA 2605 Fluorocarbon
Decabond technology was formulated to meet the more rigorous performance requirements of AAMA 2605 and is based on proven fluorocarbon resin technology. Decabond, like its sister powder, Pentabond, is formulated with the highest performance pigments, additives, resins and fillers available. All materials have proven track records in exterior coatings and the unique combination of materials has resulted in a coating with outstanding exterior durability as well as providing all performance requirements detailed under the AAMA 2605 specifications.
Minimum 50% gloss retention after 10 years Florida exposure
Maximum of 5 Delta E units, (Hunter), of color change as calculated in accordance with ASTM D 2244, Section 6.3
Limited Warranty is available for select color/gloss combinations
PTI Polyester Coatings accept graphic transfers
Polyester-TGIC Free
Polyester TGIC Free powders are exterior durable coatings that offer similar properties to TGIC Polyester but use an alternative curative, also commonly known as “Primid cured polyesters”. Polyester – TGIC Free products are available in General Industrial or Super Durable platforms.
